As promised, here’s the Tiny CPU architecture diagram. SP is the stack pointer, and is 6 bits, providing a 64-entry stack. EA is the effective address, used for data load/store from absolute or computed addresses. PC is the program counter.…
I’ve finished writing the Tiny CPU assembler, and it works. It took about four hours across two nights to get something with basic functionality. The curious can take a look at the assembler source code for details. I don’t have…
I’ve finished my experiment with fixed-size instructions for Tiny CPU, and the results are encouraging. I did a straightforward conversion to a 16-bit instruction size, with the opcode in the upper 6 bits and the address (if any) in the…
I’ve got a working CPU! You can grab the Verilog source and a testbench. The instruction set and addressing modes are as I described them in my previous post, except that I shrank the stack pointer to 6 bits (64…
I think I’m close to having this CPU fit the 128 macrocell CPLD, but running into some problems with the final details. Soon I’m going to work on a physical board layout for this CPU, at which point all the…
I think I’ve succeeded at cramming a decently useful CPU into this 128 macrocell device! I threw away my first design and started over from scratch, abandoning almost all the 6502-related elements, and working closer to a minimal instruction set…
