Windows 10 External Video Part 5 – Failure

I’m either very persistent or very stupid. After 4+ months, I’m still chasing unexplained problems with external video on the HP EliteBook x360 1030 G2 laptop that I bought in May. Recently I thought I’d finally solved it, but I was wrong, and now the problem is worse than ever. I am slowly going insane.

For the previous chapters of this story, see part 1, part 2, part 3, and part 4. Here’s a short refresher:

  • Windows 10 laptop with an external monitor, ASUS PB258Q 2560 x 1440
  • works OK during normal use
  • problems appear every couple of days, after a few hours of idle time or overnight
  • random crashes in Intel integrated graphics driver igdkmd64.sys (stopped after upgrading the driver)
  • computer periodically locks up with a blank screen and fan running 100%
  • Start menu periodically won’t open, must kill WindowsShellExperienceHost.exe
  • Windows toolbar sometimes disappears
  • Chrome window sometimes gets resized to a tiny size

This might sound like a random collection of symptoms, but I’m 99% sure they’re all somehow related to the external video. I suspect the external video is periodically disconnecting or crashing or entering a bad state, which causes errors for the Start menu, toolbar, and applications, and sometimes causes the computer to freeze.


Updates

Here’s a recap of the past month. On August 15, I switched from using an HDMI cable to a USB-C to DisplayPort cable. This did not fix the problems. On August 22, in the Windows advanced power options, I changed the Intel Graphics Settings power plan when plugged in to “maximum performance”, and also changed the minimum processor state when plugged in to 100%. The computer then went seven days without problems. On August 29, I also installed two “critical” HP updates: a BIOS update and an Intel Management Engine Driver update. Neither one mentioned anything about video issues in its release notes. The computer went a further 11 days without problems – 18 total days problem free!

Believing that the issue was resolved, on September 9 I switched back to an HDMI cable, which I prefer over DisplayPort for reasons of convenience. Within a few hours, the problems returned. I swapped the DisplayPort cable back in, and everything seemed OK.

But this morning, I once again experienced a frozen computer with a blank screen and fans running 100%. After forcing a shutdown and restart, the external monitor via DisplayPort no longer works at all. When I connect the cable, the Device Manager shows “Cable Matters USB-C Video Cable” but no external display is detected. I’ve tried rebooting and unplugging/replugging the cable at both ends, and cycling through options in the monitor’s menus, but nothing helps. Maybe the cable is broken? It was working last night, and I didn’t touch it after that.


Where Do We Go From Here?

I’m at wits’ end. Is this is a Window 10 driver problem? Laptop hardware problem? External monitor hardware problem? Cable problem? Multiple such problems at once? The sometimes long delay between problem episodes is frustrating any attempt to find a solution. Typically the problems appear every couple of days, but I recently went 18 days between problem events. That makes it almost impossible to make changes one at a time and draw conclusions about whether they helped.

A few people have suggested I try running Linux, to help determine whether this is a Windows problem or a hardware problem. I have briefly run Linux a few times, and it works OK. But I can’t devote 18+ days to running Linux simply as an experiment. Much of the software that I use is Windows-only, and I’m not interested in switching to Linux as my desktop OS right now.

I could look into repairing or returning the computer, but I’m not interested in that. It was a used/refurb machine, and not terribly expensive. While the money is not insignificant, my time and the disruption to my work are more important. I can’t be without this computer for three weeks while a reseller or PC tech experiments with it. If I need to move everything to another PC anyway, then I’ll simply go with that as the final solution.

I could try another DisplayPort cable. Maybe it simply broke somehow. That would be cheap and easy, and everything did seem OK via DisplayPort up until today.

I could also try switching back to my old 1920 x 1080 external monitor. In earlier testing from June-July, that seemed to work OK, but perhaps I just didn’t test it long enough. Reverting to the smaller and lower-resolution monitor would be a disappointment, but at this point I would be happy with any solution that works.

Finally, I could just replace the whole computer. That’s what I keep threatening to do, but I haven’t yet. Reinstalling and reconfiguring all the software on this PC would be a major pain, and the memory of that experience is still fresh in my mind from May. Several multi-gigabyte packages would need to be downloaded again, and node-locked licenses re-requested and regenerated for several software tools. When I went through the process in May, it took close to a week to get through it all.

Perhaps I could clone the existing hard drive and use it in the new PC, avoiding having to repeat all the software setup. But then I’d also be cloning all the HP-specific drivers and plugins and utilities, while missing out on all the vendor-specific stuff for the new computer. And I’d still need to regenerate the node-locked licenses for some software, even if I didn’t need to download and install them again. Maybe it’s better to start with a clean slate, even if it takes longer.

I know any computer can have hardware problems, and any OS can have bugs. But I can’t escape the feeling that this type of driver/hardware mystery is precisely why so many people dislike Windows. I feel like I’m living in one of those “I’m a Mac, I’m a PC” television commercials. If you have any suggestions for other solutions I could try (short of a sledgehammer), please share them in the comments.
